Camera

Sensor

1/2.8', 2.0 megapixel, progressive scan, CMOS

Min. Illumination

Colour: 0.01Lux (F2.0, AGC ON)
0Lux with IR on

Day/Night

IR-cut filter with auto switch (ICR)

Shutter

Auto/Manual, 1~1/100000 s

Adjustment angle

Pan: 0° to 360°, Tilt: 0° to 80°, Rotate: 0° to360°

S/N

>52dB

WDR

DWDR

Lens

Lens Type

2.8mm @F2.0

Lens Mount

M12

Angle of view(H)

106.7°

Angle of View (V)

57.1°

Angle of View (O)

115.7°

Illuminator

IR Range

Up to 30m (98 ft) IR range

IR On/Off Control

Auto/Manual

Video

Video Compression

Ultra 265, H.265, H.264

Frame Rate

Main Stream: 1080P (1920x1080), Max. 30fps; 720P (1280x720), Max. 30fps
Sub Stream: D1 (720x576), Max. 30fps; 640x360,Max. 30fps; 2CIF(704x288), Max. 30fps; CIF(352x288), Max. 30fps;

Video Bit Rate

128 Kbps~16 Mbps

OSD

Up to 4 OSDs

Privacy Mask

Up to 4 areas

ROI

Up to 8 areas

Motion Detection

Up to 4 areas


White Balance

Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2

Image Setting

Image rotation, brightness, saturation, contrast, sharpness, gain adjustable by web browser

Digital noise reduction

2D/3D DNR

Smart IR

Supported

Flip

Normal/Vertical/Horizontal/180°

HLC

Supported

BLC

Supported

Defog

Digital Defog

Network

Protocols

IPv4, IGMP, ICMP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, UPnP, HTTP

Compatible Integration

API

Client

EZStation
EZView
EZLive

Interface

Network

10/100Mbps  Base-TX Ethernet

General

Power

12VDC±25%, PoE (IEEE 802.3af)
Power consumption: Max 4.0W

Dimensions (Ø x H)

Φ118 x 96mm

Weight

0.27kg

Material

Metal + Plastic

Working Environment

-20°C ~ 50°C (-4°F ~ 122°F), Humidity: ≤95% RH (non-condensing)

Surge Protection

4KV

Ingress Protection

IP67
